Engine parameter

Single cylinder, air cooled, four stroke, horizontal natural

Exhaust volume: 123.7ml

Bore * stroke: 54 x 54

Compression ratio: 9.3:1

Ignition mode: C.D.I

The maximum power and the corresponding speed: 6.3 KW/8500r/min

The maximum torque and the corresponding speed: 8.5 N.m/8000r/min

Clutch type: multiple disc oil bath type, manual clutch

Methods: pressure and splash lubrication

Start mode: electric, kick starter

The dimension parameters

Vehicle dimensions: (length * width * height) 1640 x 400 x 1080 mm

Wheelbase: 1086 mm

The minimum height from the ground: more than 270 mm

Wheelbase: 1176mm

Car body

The main frame: chrome molybdenum steel

Front suspension: front shock absorber length 720mm, stroke 140mm,

Rear suspension: rear shock absorber length of 275mm, 800LBS, the number of pounds is not adjustable, without air bag,

Transmission system: chain drive, small output sprocket 14 teeth, 34 teeth, 428 driven big sprocket chain

The front wheel assembly: 19 * 6.00-10 4PL tire specifications, stampingwheel rim

The rear wheel assembly: 18 * 6.50-8 4PL tire specifications, stampingwheel rim

Front brake system: disc, disc diameter 190mm

The rear brake system: disc brakes, disc diameter 190mm

Vehicle weight: 65 + 1 kg

Packing

Packaging: the frame size (length * width * height) 1340*400*670

Packing frame weight: 15 kg
