Engine/ Fuel
Brand ODES
Engine Type V-Twin Cylinder 4 Stroke EFI
Horsepower 60 Horsepower
Engine Oil Royal Purple 10w/40 Max Cycle Synthetic Oil™
Max Torque 73N.m (4000r/min)
Compression Ratio 10:3:1
Cooling Water Cooled - Front Mount Radiator
Cooling Lubricant Royal Purple Purple Ice™
Intake/Air Front Snorkel, Center Intake, Rear Intake
Top Speed 58MPH (depending on rider weight, load and driving conditions)
Transmission and Drive
Drive Type Fully Automatic
Gears L-H-N-R-P
Clutch CVTech Clutch System™
Drive Shaft Drive Front/Rear
4x4 Capable 2x4, 4x4, Differential Locking Switch
Fuel and Ignition System
Starting System Push To Start
Ignition Delphi-EFI™
Fuel System Electronic Fuel Injection-Delphi EFI™
Fuel Capacity 6 Gallons
Emissions Control Catalytic Converter Installed
Steering
Steering Rack and Pinion
Steering Wheel 6 Bolt Point Mount Gripper Steering Wheel
Suspension
Front Suspension Independent Double Wishbone
Rear Suspension Independent Double Wishbone
Front A-Arm Dual Top and Bottom A-Arms
Rear A-Arm Dual Top and Bottom A-Arms
Brakes, Tires and Wheels
Front/Rear Brakes 4 Wheel Disc Brakes
Front Tire Wanda 27x9x14
Rear Tire Wanda 27x11x14
Front Wheel 14" Aluminum Wheels
Rear Wheel 14" Aluminum Wheels
Front Travel 7"
Rear Travel 6"
Cargo Bed
Cargo Bed Operation Electronic Dump Function
Cargo Bed Capacity 330 LBS
Measurements and Dimensions
UTV Dimensions 115"(L) x 64"(W) x 74.5" (H)
Cargo Bed Dimensions 31.5"(L) x 43.9" (W) x 12.4" (H)
Unit Width 64 INCHES
Seat Width 458MM
Front Shock Dimensions 490MM TALL WITH 297MM SPRING SETTING
Rear Shock Dimensions 450MM TALL WITH 277MM SPRING SETTING
Drive Bar Thickness 18MM
Drive Axle Thickness 23MM
Air Filter Diameter 65MM
A-Arm Thickness 28MM
Radiator Dimensions 650MM Diagonal
Brake Rotor Dimensions 190MM Brake Rotor Width
Wheel Lug Bolts 10MM
Dry Weight 1212 LBS
Ground Clearance 14.4 Inches
Towing Capacity 2200LBS (330 Tongue)
Special Features and Included Accessories
FRONT WINCH STANDARD 3500LBS
PATENT REAR WINCH STANDARD 3500LBS
FRONT WINDSHIELD INCLUDED
ROOF INCLUDED
2" TOW BALL WITH HITCH INCLUDED
HALF DOORS INCLUDED
LED LIGHTS INCLUDED
REAR BUMPER INCLUDED
SNAP PUSH PINS FOR INTERIOR PLASTICS INCLUDED
STICHED SEATS INCLUDED
DAYTIME RUNNING LIGHTS INCLUDED
INTEGRATED MOLDED CUPHOLDERS INCLUDED
OPEN AIR FILTER INTAKE - WASHABLE INCLUDED
